Traxxas Mini XRT VXL-3S 4wd

Extreme 3s Performance. Compact Size.
Mini XRT® is a true rocket with full 1/10 scale Velineon® 3s brushless power in a compact, take-anywhere size. Mini XRT lives up to its name with unprecedented 55+ mph speed and ferocious acceleration, backed by race-inspired engineering and unrivaled toughness. Mini XRT shatters all expectations with big-scale performance and toughness that fits in a backpack.

Bred For Performance
Like its X-series™ counterpart, Mini XRT was engineered with maximum focus on speed, handling, and performance. A low, ultra-wide stance delivers supreme confidence and control as Mini XRT muscles its way to 55 mph and beyond. It’s a whole new way to experience big-scale fun and toughness in a backpack-friendly size.

1/10 Scale VXL-3s Brushless Power
The Velineon VXL-3s brushless power system is the heart of Traxxas’ fastest and most powerful 1/10 scale vehicles. For the first time ever, this extreme 11.1-volt powerplant now comes installed in a compact platform. The result is astonishing acceleration, 55+ mph speed, and wheel-standing power at any rpm.

1/10 Scale 4X4 Driveline
Adding 3s Velineon power to a compact platform requires bold engineering. Mini XRT comes outfitted with the proven driveline components of Traxxas’ toughest 1/10 scale 4X4 trucks. Front, center, and rear steel-gear differentials, along with 32-pitch gearing and HD driveshafts, far exceed requirements for strength and long life.

Maxx Chassis Technology
Mini XRT is the newest truck to use the revolutionary chassis design pioneered in Mini Maxx®. Perfectly sized to fit into a backpack, Mini XRT transforms full-scale performance and durability into a supremely compact chassis. Just one look at the rigid, unified structure and you know it’s built Maxx tough.

Clipless Body
Mini XRT’s innovative clipless body is rock solid and easy to use. Just drop the body onto the chassis and snap it into place for a secure hold. When it’s time to change the battery, depress the tabs under the wheel wells and lift to access the chassis. Nothing else is faster or latches more securely.

WideMaxx Suspension
Mini XRT relies on proven WideMaxx® suspension design to deliver sure-footed grip and laser-focused handling. Mini XRT sits low and wide for hard cornering and maximum stability at speed. The long-travel suspension delivers refined damping control to maintain composure over the roughest terrain.

Features:
40+ mph with included 2-cell LiPo Battery. 55+ mph with optional 3-Cell LiPo Battery (sold separately)
Clipless Body Mount System
Quick and easy installation and removal
Nerf bar channels for side body support
Reinforced for extra protection against tearing
Functional rear wing
VXL-3s Waterproof Electronic Speed Control
Three programmable drive profiles
Sport Mode - forward / brake / reverse
Race Mode - forward / brake
Training Mode™ - 50% forward / brake / 50% reverse
Heat sink accepts accessory cooling fan (3340)
Traxxas EZ-Set® one-button setup
Built-in two-stage low-voltage detection
Velineon 3500 Kv Brushless Motor
Ultra high-temperature sintered neodymium magnets
Low-maintenance design
Precision-balanced rotor
Efficient high-speed ball bearings
3500 Kv
Brilliant blue-anodized finish
Battery and Charger Included
High-capacity 2-cell LiPo battery
7.4 volts
3500 mAh for extended run time
2-amp USB-C charger
iD® technology for faster, safer charging
TQi 2.4 GHz High Output 2-Channel Radio System
Programmable multi-function knob
Adjustable steering and throttle percentage (dual rates)
Adjustable steering and throttle sensitivity (exponential)
Adjustable steering and throttle end points
5-channel micro receiver (6533) with fail-safe security
Patented waterproof receiver box with easy-access plug
Traxxas Stability Management (TSM)
Improves straight line acceleration and braking on low-traction surfaces
Maintains steering composure to allow throttle-on powerslides
Never dulls throttle or slows the truck
Adjusts from off to 100% assistance from the transmitter
1/10 Scale 4X4 Drivetrain
Full-time shaft-driven 4-wheel drive
1/10 scale extreme-duty telescoping driveshafts
Direct-drive (no transmission)
Sealed center differential
Large 32-pitch gears
Sealed planetary steel-gear differentials (F&R)
Fixed gear mesh system
Modular Composite Chassis
Modular chassis with interlocking front and rear bulkheads
Absorbs and distributes impact energy
Easy to service and access components
Driveline is sealed in the chassis to keep out dirt
Easy Battery Access
Battery is protected deep in the chassis
Battery hold-down pivots for easy access
More secure than conventional retention systems
Steering
1/10 scale 2075X waterproof high-torque, metal-gear servo
Heavy-duty double-shear bellcranks
Cam-operated servo saver
Suspension
Heavy-duty, double-shear suspension arms
Tough composite formula resists impact damage, even in cold weather
Dual-wishbone design
Extra tough outer suspension components
Oil-Filled Ultra Shocks™
1/10 scale shocks
Large oil capacity
Easy to tune
Bumpers and Skid Plates
Tough energy absorbing front bumper
High-angle front skid plate
Rugged interlocking skid plates
Smooth undertray eliminates snags
Integrated nerf bars for side impact resistance
Wheels and Tires
New graphite gray mini XRT wheels
Gravix tires with foam inserts
Excellent traction on or off the road
Directional tread pattern for quieter running
Thick center carcass resists ballooning
Hex Hardware with Rust-Resistant Black Oxide Coating
Sealed Ball Bearings

Truck Specs:
Length:    14.8 inches (376 mm)
Front Track:    11 inches (279 mm)
Rear Track:    11 inches (279 mm)
Ground Clearance:    1.06 inches (27 mm)
Weight:    3.99 pounds (1.81 kg)
Height:    5 inches (127 mm)
Wheelbase:    8.66 inches (220 mm)
Shock Length:    3.45 inches (88 mm)
Tire Diameter:    3.7 inches (94 mm)
Wheel Diameter:    2.1″ (53 mm) outer, 2.6″ (66 mm) inner
Speed Control:    VXL-3s brushless ESC
Motor (electric):    Velineon 3500 (3500 Kv)
Transmission:    Direct-drive with center differential
Overall Drive Ratio:    7.36:1
Differential Type:    Planetary, steel gear
Gear Pitch:    32
Chassis Structure/Material:    Composite modular tub
Brake Type:    Electronic
Drive System:    Shaft-driven 4WD
Steering:    Double-shear bellcrank
Wheels & Tires:    Black dual-profile XRT wheels with pre-glued 4″ Gravix tires
Radio System:    TQi 2.4 GHz high output(2-channel) w/ TSM
Servo:    Waterproof high-torque, metal-gear 2075X
Top Speed:    55+ mph
Skill Level:    1
Battery Tray:    113 mm L x 41 mm W x 22 mm H
Required Batteries:    4 “AA” (transmitter)

What’s In The Box:
Mini XRT Ready-To-Race monster truck
Velineon VXL-3s brushless power system
3500 mAh 2-cell LiPo battery
2-amp USB-C charger
Quick Start Guide
TQi 2.4 GHz radio system
High quality maintenance tools
What You’ll Need:
AA Alkaline Batteries
Four AA alkaline batteries for the transmitter

Charging Accessories
Power adapter 2912 and power cable 2916 recommended for peak charging performance.

Motor Specs:
Type:    Velineon 3500 Kv sensorless brushless
Weight:    9.24 ounces (262 g)
Length:    3.03 inches (77 mm)
Diameter:    1.41 inches (36 mm)
Connector Type:    3.5 mm bullet

ESC Specs:
Input Voltage (cells):    7.4 – 11.1 volts, 2s–3s LiPo
Case Size:    2.19″ (56 mm) x 1.54″ (39 mm) x 1.3″ (33 mm)
Weight:    3.84 ounces (109 g)
BEC Voltage:    6.0 volts
Reverse Delay:    Yes, with lockout
Thermal Protection:    Two-stage thermal shutdown
Ports:    Auxiliary fan
